Crash-only confidence, part 1: from random kills to exact boundaries

Posted · 17 min read
Preview Image
Crash-only confidence, part 1: from random kills to exact boundaries

TL;DR: BeachDB v0.0.4 turns crash testing from random SIGKILLs into crashes aimed at named engine boundaries. It ships a controller/worker harness, replayable artifacts, and a tiny crashhook layer with failpoints across the WAL and flush paths. The goal is simple: stop asking “did it survive?” and start asking “what exactly survived, at which boundary, and why?”

Code is here.

This is part of an ongoing series — see all posts tagged #beachdb.

A blunt instrument

BeachDB has had crash testing since v0.0.1. The original setup was simple: spawn a writer subprocess that writes keys in a loop, wait a random number of milliseconds, kill -9 the process, reopen the database, check what survived. I first mentioned it in the “Crash recovery” section of the WAL post.

That was good enough for the first question I cared about: does the WAL actually work, or am I just telling myself a nice story about durability? It caught real bugs. It gave me confidence that acknowledged writes survive process death.

But it was still a blunt instrument. It could tell me that something survived. It could not tell me why. And it definitely could not tell me at which internal boundary the process died.

At a high level, the old setup looked like this:

sequenceDiagram
  autonumber
  participant O as Orchestrator
  participant W as Writer subprocess
  participant DB as BeachDB
  participant S as Scratch file

  O->>W: Spawn writer
  loop Until kill lands
    W->>DB: Put in a loop
    DB-->>W: Success
    W->>S: Append committed key(s)
  end
  O->>O: Sleep random duration
  O->>W: SIGKILL
  O->>DB: Reopen database
  O->>S: Read claimed committed keys
  O->>O: Compare survivors vs scratch file

Not useless. Just fuzzy in exactly the places I now cared about.

One exact boundary I wanted to test

At some point I stopped wanting “more random kills” and started wanting one very specific answer.

Suppose a Put() crosses the WAL fsync boundary, and then the process dies before the normal write path finishes.

What should happen on reopen?

For that boundary, the answer should be: the write comes back.

If the WAL append happened, the fsync returned, and the process dies before it gets to finish the rest of the path, recovery should replay that WAL record and rebuild the state. That is the whole point of the log in the first place.

Scope note: this harness models process death in a surviving kernel. That distinction matters. This is not a power-loss / kernel-panic / “the machine fell into the sea” test harness. In a process-crash test, buffered bytes, kernel page cache state, and already-fsync‘d data all behave differently. The harness needs to keep those boundaries honest.

That may sound obvious written out like this, but the old crash loop could only exercise that boundary accidentally. It could kill the process around the fsync. It could not tell me, with a straight face, that the kill landed after the fsync and before the rest of the write path.

That was the itch.

Why wall-clock kills were not enough

Once I looked at the problem through that one boundary, the limitation of wall-clock kills became obvious.

Random SIGKILLs are realistic, but sloppy. They tell you the process died somewhere during the write path. They do not tell you whether it died before the WAL append, after the append, after fsync, or halfway through building an SSTable.

The old setup also had three practical problems I kept tripping over:

  • Non-deterministic timing. “It failed once at cycle 37” is not a debugging strategy.
  • Coarse verification. The orchestrator only knew which keys the writer claimed it committed through a scratch file with newline-delimited keys. There was no clean notion of “acked vs. in-flight” at the operation boundary.
  • No internal visibility. I could kill from the outside, but I could not target “right after WAL sync” or “force SSTable publish to fail.”

So the new harness had to buy me four things:

  1. A deterministic workload I can replay exactly.
  2. A protocol that tells me, for each operation, whether the subprocess started it, acked it, or failed it.
  3. The ability to crash or inject faults at named internal engine boundaries.
  4. An artifact from each run that I can inspect, replay, and diff.

The new architecture: controller and worker

The new harness splits cleanly into two processes with boring, explicit jobs.

sequenceDiagram
  autonumber
  participant C as Controller
  participant W as Worker (subprocess)
  participant DB as BeachDB

  C->>C: Generate deterministic workload from seed
  C->>W: Spawn subprocess (optional failpoint env)
  W->>DB: Open database
  W-->>C: ready
  loop For each operation
    C->>W: {op: put/delete/batch, ...}
    W-->>C: start
    W->>DB: Execute operation
    W-->>C: ack (or fail)
  end
  C->>W: SIGKILL after planned delay
  C->>DB: Reopen database
  C->>C: Verify recovered state against oracle

The controller owns the workload, the crash/fault schedule, the oracle, and the artifact written at the end of the run. It does not participate in the write path itself. It only touches BeachDB directly when it reopens the database after a kill or an injected failure.

The worker is intentionally thin: receive one operation at a time on stdin, call the BeachDB API, emit lifecycle events on stdout. The protocol between them is NDJSON with base64-encoded keys and values, so binary payloads survive the round trip without text-parser nonsense.

And yes, the harness is deliberately slow.

The old writer generated its own keys in a loop, which meant the controller had no precise idea which operation was in flight when the kill landed. The new one does one operation at a time: one op, one start, one ack/fail, then move on. Throughput goes down. Signal goes up. For a crash harness, that trade is not exactly heartbreaking.

The contract the harness now enforces

That architecture gives the harness a protocol, and the protocol gives the harness a contract.

The worker emits four lifecycle events:

  • ready - database is open
  • start - about to execute the operation
  • ack - the operation succeeded and the DB call returned nil
  • fail - the operation returned an error

From those events, the controller enforces a conservative harness-wide contract:

  • Acked operations must be reflected after recovery.
  • The single started-but-not-acked operation is indeterminate by default. It may be present or absent after reopen.
  • Never-started operations are irrelevant to that crash cycle.

That “single ambiguous operation” rule is the big upgrade over the old harness. The commit frontier is no longer fuzzy.

There is one important nuance, though: this is the harness’s default contract, not a custom proof rule for every failpoint.

Some boundaries deserve stronger claims. wal_after_sync is one of them: once the WAL fsync boundary is crossed, I expect recovery to bring the write back. But in v0.0.4, the oracle stays conservative: a started-but-not-acked operation is still allowed to be present or absent. The artifact tells me exactly where the process died; the oracle does not yet encode per-failpoint rules.

wal_after_append is different. wal.Writer.Append writes into a bufio.Writer, so the record may still be sitting in process memory. It has not crossed the durable boundary, and may not even have reached the kernel yet. That operation must not be treated as durably acknowledged.

That is one of those annoying details that becomes less annoying once it saves you from lying in a blog post.

In the engine, that write-path boundary looks like this:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

// Append the changes to the WAL file via wal.Writer
if err := db.wal.Append(encoded); err != nil {
    return fmt.Errorf("beachdb: appending to WAL: %w", err)
}

// FAILPOINT: wal_after_append
crashhook.CrashIfArmed(crashhook.PointWALAfterAppend)

// Try to sync the WAL to disk if the option is set
if err := db.syncWALLocked(); err != nil {
    return err
}

// Apply the Batch operations to Memtable
db.applyOperations(ops)

And inside syncWALLocked():

1
2
3
4
5
6
7
8
9
10
11

// FAILPOINT: wal_sync_error
if err := crashhook.MaybeFault(crashhook.FaultWALSyncError); err != nil {
    return fmt.Errorf("beachdb: syncing WAL: %w", err)
}

if err := db.wal.Sync(); err != nil {
    return fmt.Errorf("beachdb: syncing WAL: %w", err)
}

// FAILPOINT: wal_after_sync
crashhook.CrashIfArmed(crashhook.PointWALAfterSync)

That is the write-path boundary in code form: append into the WAL writer, optional crash, flush + sync, optional crash, then move on.

Replayable artifacts

Every run starts with a seed. That seed determines the workload: which keys, which values, which operations, in what order. The crash schedule is derived from it too.

That means a failing run is not “well… something weird happened once.” It is a replayable artifact.

1
2
3

./bin/crash replay \
  --artifact=/tmp/beachdb-crash-artifacts/crash-20260419T213015.123Z.json \
  --dbdir=/tmp/beachdb-crash-replay-db

The artifact captures the things I actually care about:

  • the run configuration and seed
  • the generated workload
  • the ordered stream of worker events
  • per-cycle metadata and verification results
  • the last acknowledged op ID
  • the first failure, if there was one

One cycle’s evidence in the artifact looks more like this:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

{
  "seed": 42,
  "last_acked_op_id": 16,
  "events": [
    {"cycle": 0, "event": {"kind": "ready"}},
    {"cycle": 0, "event": {"kind": "start", "op_id": 17}}
  ],
  "cycles": [
    {
      "index": 0,
      "exit_code": 86,
      "last_event": {"kind": "start", "op_id": 17},
      "verification": {
        "checked_keys": 23,
        "allowed_optional_ops": [17]
      },
      "crash_point": "wal_after_sync"
    }
  ]
}

That is trimmed for readability, but it shows the important shape: worker events in one stream, cycle-level metadata in another, and enough information to replay the run and reason about the last in-flight operation.

This would have saved me hours during the SSTable milestone. Instead of “it failed once and now I can’t make it fail again,” I get a file I can hand to someone else and say: here, run this.

Failpoints and hook sites

The controller/worker split solves the “what was in flight?” problem. It does not solve the “crash exactly here” problem.

An external SIGKILL is still subject to scheduler timing. Useful, realistic, but imprecise.

That is what BeachDB’s tiny internal crashhook layer is for. It is not the crash harness itself; the harness lives under cmd/crash.1 The hook package is just the small internal layer that lets the harness aim at named engine boundaries.2

The shape is modeled after RocksDB’s test-only kill points: named hooks in the engine, normally dormant, armed by a stress/crash harness when you want the process to die at a particular edge.34 BeachDB’s version is smaller, less general, and wearing floaties in the shallow end.

Other engines attack similar bugs from different angles: LevelDB has recovery/corruption tests, Pebble models crashable filesystems, and Badger keeps a Jepsen-inspired bank workload around transactional invariants.567

BeachDB keeps the implementation intentionally boring:

  1. put named hooks in engine code paths
  2. leave them dormant by default
  3. arm them through the worker process environment
  4. when triggered, either crash the process or return a synthetic error

The hook layer lives in internal/crashhook and exposes two primitives:

  • CrashIfArmed(point) - if the named point is armed, call os.Exit(86) immediately
  • MaybeFault(point) - if the named point is armed, return a synthetic error

Both are activated by environment variables passed from the controller to the worker subprocess. In normal operation they are inert.

The implementation is intentionally tiny:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29

func CrashIfArmed(point string) {
    if point == "" || os.Getenv(EnvCrashPoint) != point {
        return
    }
    if !crashConsumed.CompareAndSwap(false, true) {
        return
    }
    exitFunc(CrashExitCode)
}

func MaybeFault(point string) error {
    if point == "" || os.Getenv(EnvFaultPoint) != point {
        return nil
    }
    if !faultConsumed.CompareAndSwap(false, true) {
        return nil
    }

    switch point {
    case FaultWALSyncError:
        return ErrInjectedWALSync
    case FaultSSTPublishError:
        return ErrInjectedSSTPublish
    case FaultSSTWriteError:
        return ErrInjectedSSTWrite
    default:
        return nil
    }
}

I like this shape a lot because it keeps the hook layer boring on purpose: environment variables arm the point, atomics make it one-shot per process, and the engine code gets tiny, readable hook sites.

There are seven hook sites in the engine right now, and every one is marked with a // FAILPOINT: comment so I can find them all with one grep:

1
2
3
4
5
6
7
8

$ grep -rn "// FAILPOINT:" engine/
engine/db.go:191:  // FAILPOINT: wal_after_append
engine/db.go:411:  // FAILPOINT: wal_sync_error
engine/db.go:420:  // FAILPOINT: wal_after_sync
engine/db.go:652:  // FAILPOINT: sst_publish_error
engine/db.go:662:  // FAILPOINT: flush_after_publish
engine/db.go:677:  // FAILPOINT: sst_write_error
engine/db.go:726:  // FAILPOINT: flush_after_file_sync

They fall into two buckets: crash points, which simulate process death, and fault points, which inject errors and let the process keep unwinding normally.

The important thing to remember is that the “current oracle rule” column describes what v0.0.4 enforces automatically, not necessarily the strongest claim I eventually want the engine to prove.

Wide table ahead, make sure to scroll right to see all columns!

FailpointTypeBoundaryCurrent oracle ruleFuture stricter rule
wal_after_appendCrashWAL writer accepted the record, but before flush and fsyncPending op may be present or absentSame
wal_after_syncCrashWAL fsync returnedPending op may be present or absentPending op must be present
wal_sync_errorFaultWAL sync returns a synthetic errorOperation must not be ackedSame
sst_write_errorFaultSSTable write fails before touching the filesystemOperation must fail cleanlySame
flush_after_file_syncCrashSSTable file and parent directory are durable on diskStartup must remain coherentManifest should define ownership precisely
sst_publish_errorFaultSSTable exists on disk, but publish failsReopen must remain coherentManifest should define ownership precisely
flush_after_publishCrashSSTable is published into the engine’s in-memory stateReopen must remain coherentManifest should make this explicit

That distinction matters.

wal_after_sync is a crash point at a durable boundary. The process dies after the WAL sync returns, and on reopen I expect WAL replay to recover the write. The current oracle does not enforce that special case yet, but the artifact makes the boundary visible enough to inspect and replay.

sst_publish_error is different. It is a synthetic error path. The interesting question is not “did the process die?” but “if the SSTable file already exists on disk and publish fails, does reopen still recover coherently?”

wal_after_append is the sneaky one. The process dies after the WAL writer accepted the record into its buffer, before the flush and before the durable boundary. In this harness, that operation is not acknowledged as durable, and after reopen it may or may not be present. The important rule is not whether it sometimes appears. The important rule is that the harness is not allowed to require it.

The flush path has the same shape:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

func (db *DB) publishFlushedSSTLocked(sstReader *sstable.Reader) error {
    // FAILPOINT: sst_publish_error
    if err := crashhook.MaybeFault(crashhook.FaultSSTPublishError); err != nil {
        return fmt.Errorf("beachdb: publishing SSTable: %w", err)
    }

    db.flushErr = nil
    db.ssts = append(db.ssts, sstReader)
    db.immMem = nil
    db.nextSSTID++

    // FAILPOINT: flush_after_publish
    crashhook.CrashIfArmed(crashhook.PointFlushAfterPublish)

    return nil
}

And during file creation itself:

1
2
3
4
5
6
7
8
9
10
11
12

// FAILPOINT: sst_write_error
if err := crashhook.MaybeFault(crashhook.FaultSSTWriteError); err != nil {
    return nil, fmt.Errorf("beachdb: writing SSTable: %w", err)
}

// Sync parent directory so the new file's directory entry is durable
if err = syncDir(filepath.Dir(path)); err != nil {
    return nil, fmt.Errorf("beachdb: syncing directory after flush: %w", err)
}

// FAILPOINT: flush_after_file_sync
crashhook.CrashIfArmed(crashhook.PointFlushAfterFileSync)

That tiny footprint is one of my favorite parts of the whole thing. One comment, one call, and suddenly the engine has named edges I can attack on purpose.

Oracle and invariants

The last piece is the oracle that runs after every crash/reopen cycle.

This is not just a bag of “acked keys.” That would be too naive once the workload starts overwriting keys or deleting them.

Instead, the oracle builds the final expected visible state from the ordered stream of acked operations:

  • later Puts overwrite earlier visible values for the same key
  • Deletes turn that key into a tombstone / not-found state
  • batch operations expand into their nested Put / Delete items and are applied in order too
  • the expected answer is the final visible state after applying the acked prefix in order

After reopening the database, the controller reads the relevant keys back and checks:

  1. the visible state derived from acked operations matches what the database returns
  2. the single started-but-not-acked operation is allowed to be present or absent
  3. keys that were never started do not magically appear with values they were never given

That is basically reference-model testing stretched across a process boundary. BeachDB already uses the same idea in internal/testutil.Model for unit tests. Here I am just applying it to crash cycles instead of in-process data structures.

The obvious next step is to teach the oracle boundary-specific expectations. For example, wal_after_sync should eventually mean: “this pending operation crossed the durable WAL boundary, so missing after recovery is a failure.” v0.0.4 gives me the artifact and exact crash point first; stricter assertions can grow on top.

Running it

A short smoke run:

1

make crash-check

A longer local run:

1
2
3
4
5
6

./bin/crash run \
  --dbdir=/tmp/beachdb-crash-db \
  --artifact-dir=/tmp/beachdb-crash-artifacts \
  --cycles=500 \
  --seed=42 \
  --ops=1000

And replaying a failure:

1
2
3

./bin/crash replay \
  --artifact=/tmp/beachdb-crash-artifacts/crash-20260419T213015.123Z.json \
  --dbdir=/tmp/beachdb-crash-replay-db

What changed in my confidence

The biggest lesson was not about crash testing specifically. It was about the gap between “tests pass” and “I trust this.”

The old harness gave me green tests and a general sense that the durability story was probably fine. The new one lets me target exact boundaries, inspect the evidence, and grow the oracle toward sharper boundary-specific claims.

That is a different kind of confidence.

Once I could say “crash here, at this exact internal edge” or “inject this exact fault after the file is already durable,” the whole discussion got sharper. The durability story stopped being “I wrote a lot of tests and they pass” and started being “I can tell you what happens at this boundary, why it happens, and which artifact proves it.”

That is the kind of evidence I want from a storage engine, even a toy one.

What’s next

The next milestone is Manifest.

That is not just “metadata.” It is the thing that will let BeachDB say which SSTables belong to the current durable view of the database. Right now, startup discovers *.sst files by scanning the directory. That is simple, honest, and temporary.

The crash harness in this post gives me the weapon. The manifest gives me better targets.

After that: merge iteration, compaction, and the slow process of turning “a bunch of sorted files” into a coherent version history.

Until we meet again.

Adios! ✌🏼

Notes & references

  1. BeachDB v0.0.4 crash harness implementation: cmd/crash/ ↩︎

  2. BeachDB v0.0.4 crash hook layer: internal/crashhook/crashhook.go ↩︎

  3. RocksDB’s crash-test driver: tools/db_crashtest.py. The whitebox mode runs db_stress with kill_random_test, which is the closest ancestor of the shape I wanted. ↩︎

  4. RocksDB’s test hook machinery: test_util/sync_point.h. The TEST_KILL_RANDOM and TEST_SYNC_POINT macros are the important bits for this post. ↩︎

  5. LevelDB has smaller but still useful recovery/fault-injection examples in db/fault_injection_test.cc and db/corruption_test.cc. ↩︎

  6. Pebble’s current test filesystem has a nice explicit crash model in vfs/mem_fs.go, especially NewCrashableMem and CrashClone. ↩︎

  7. Badger is a less direct failpoint reference, but a useful adjacent example: its README calls out filesystem-anomaly testing, and its Jepsen-inspired bank workload lives in badger/cmd/bank.go, with a nightly workflow in ci-badger-bank-tests-nightly.yml. ↩︎

Programming
beachdb databases testing crash-testing fault-injection
This post is licensed under CC BY 4.0 by the author.
